Ashirvad SWR Type-A Double Socket Pipe PUSHFIT

Overview

The Ashirvad SWR Type-A Double Socket Pipe has sockets at both ends, used for soil, waste, and rainwater drainage runs where you need to join pipe lengths on both sides. It's available in two diameters and four cut lengths, so you can pick the closest length to your run and minimise offcuts.

Key Specifications

• Material: uPVC (SWR grade)
• End type: Double socket (both ends), PUSHFIT joint
• Use: Soil, waste, and rainwater drainage lines
• Available diameters: 3 inch (75mm) and 4 inch (110mm)
• Available lengths: 2 ft, 4 ft, 6 ft, and 3 metres, in each diameter

Available Sizes

• 4 inch (110mm) — for soil/toilet lines and main vertical stacks, in 2ft, 4ft, 6ft, and 3M lengths.
• 3 inch (75mm) — for basin, sink, and smaller waste lines, in 2ft, 4ft, 6ft, and 3M lengths.

How to Use

1. Measure your drainage run and pick the closest matching length to reduce cutting and joints.
2. Apply Ashirvad rubber lubricant to each socket before assembly.
3. Push adjoining pipes/fittings fully into each socket until they seat.
4. Support the pipe run with clamps at regular intervals.

Frequently Asked Questions

Why are there different lengths for the same diameter?
Shorter lengths (2ft, 4ft) suit tight runs or repairs, while 6ft and 3M lengths cover longer straight runs with fewer joints.

Which diameter should I use for a toilet connection?
Use the 4 inch (110mm) size for soil/toilet lines; 3 inch (75mm) suits basin and sink waste lines.
